198 Rockwell Automation Publication 2198-UM002G-EN-P - February 2019
Chapter 6 Configure and Start the Kinetix 5700 Drive System
Configure the Drive
You can include the drive in your Studio 5000 Logix Designer® application by
adding it to a configured EtherNet/IP module or controller under the I/O
configuration tree. After setting network parameters, you can view the drive
status information in Studio 5000® environment and use it in your Logix
Designer application.
Set the Network Parameters
You must program network parameters by using the LCD display.
1. From the LCD display, select SETUP>NETWORK and choose
between STATIC IP and DHCP.
The default setting is STATIC IP.
2. If STATIC IP, then press to configure the following parameters:
• IP address
•Gateway
•Subnet mask
Settings are stored in nonvolatile memory. IP addressing can also be changed
through the Module Configuration dialog box in RSLinx® software. Changes
to the IP addressing take effect after power is cycled. The drive is factory
programmed to static IP address of 192.168.1.1.
Refer to Setup Screens
on page 192 for help setting the network parameters.
Studio 5000 Logix Designer
For help using the Studio 5000 Logix Designer application as it applies to
configuring the ControlLogix® or CompactLogix™ controllers, refer to
Additional Resources
on page 13.
Version History
Each release of the Studio 5000 Logix Designer application makes possible the
configuration of additional Allen-Bradley® motors, actuators, power supplies,
and drive features not available in previous versions.
IMPORTANT To configure additional motors, actuators, and drive features with your
Kinetix 5700 servo drive, you must have drive firmware 4.001 or later.
Refer to Table 110
to determine if you need to install the Kinetix 5700
Add-on Profile.
