Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 93
Chapter 4
Connector Data and Feature Descriptions
This chapter illustrates connectors and indicators for the Kinetix® 5700 drive
system components, including the DC-bus power supply, regenerative bus
supply, single-axis inverter, dual-axis inverter, and accessory modules. Also
included in this chapter are connector pinouts and descriptions for
Kinetix 5700 system components.
Topic Page
Kinetix 5700 Connector Data 94
Understand Control Signal Specifications 108
Feedback Specifications 114
Functional Safety Features 125
