GE LOGIQ P7 Service Manual

GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
3-38 Section 3-8 - Printer Installation
3-8-5-1 UP-D898 - Printer Settings
1) Call up the ‘Printer Preferences’; operation see: Section 3-8-5 "Adjustment of Printer Settings" .
2) Select the
MAIN page (see: Figure 3-25 below) and select:
- Paper: 1920x1280
- Orientation: Landscape
- Interpolation Method: Bilinear
3) Select the
DENSITY ADJUST page (see: Figure 3-25 above) and select:
-Dark = 0; Light = 0
4) For saving the adjusted printer settings click APPLY
and then OK.
Finally close the ‘Printers’ -window with the close button and exit System Setup with SAVE&EXIT
.
Figure 3-25 Layout + Density Adjust page
