GE
RAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019)
S
ERVICE
M
ANUAL
8-192
S
ection 8-49 - Replaceme
nt of BBC
Section 8-49
Replacement of BBC
8-49-1
Manpower
1 person, 30 minutes
8-49-2
Tools
Standard Phillips Screwd
river, Hex-Wrench
8-49-3
Removal Procedure
1)
Unscrew 2 screws
to remove COVER BRKT.
2)
Disass
emble BATTERY
PACK COVER BRKT.
Figure 8-239 Unscrewing
2 screws to remove COVER BRKT
Figure 8-240 Disassembli
ng BA
TTER
Y P
ACK COVER BRKT
517
519
