GE
DRAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019
)
S
ERVICE
M
ANUAL
Chapter 8 -
Replacement Pr
ocedures
8-65
8-7-4
Installation Procedure
1)
Cover to be installed in reverse order of removal.
2)
Make sure “latches” on both sides ar
e engaged.
NOTE:
For M
id and High Ca
binet type,
there is “Gu
ide Rail” for
installation
.
Figure 8-47 Guide Rai
l and latch
8-7-5
Functional Check
Visual inspection only.
