GERAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

8-64 Section 8-7 - Replacement of Top Cover

Section 8-7

Replacement of Top Cover

8-7-1 Manpower

1 person, 5 min.

8-7-2 Tools

None required.

8-7-3 Removal Procedure

1) Top Cover shapes differ for each configuration, but removal/installation procedure are the same.

Figure 8-45 Low Cabinet and High cabinet

2) Slide out Top Cover toward front of the console. No tools required.

Figure 8-46 Slide out Top Cover

Low Cabinet High Cabinet
