8-66
Section 8-8 - Replacement of Side Cover
Section 8-8
Replacement of Side Cov
er
8-8-1
Manpower
1 person, 15 min.
8-8-2
Tools
Standard Phillips Screwdriver.
8-8-3
Removal Procedure
8-8-3-1
Removal Procedure -
Side Cover (L)
1)
Remove Top Cover.
2)
Re
move 3 screws
for Side C
over (L).
Figure 8-49 Side Cover screw
Figure 8-48 Removal of T
op cover
391
393
