GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-137

Section 8-25

Replacement of Battery

8-25-1 Manpower

1 person, 1 hour

NOTE: LP9/P7 BUM 5504583 provides the information, "Refreshing the battery" in Chapter 3 Preparing to

System for Use. The recommended procedure can be executed by user for maintaing battery life.

8-25-2 Tools

Standard Phillips Screwdriver.

8-25-3 Removal Procedure

1) Unscrew 12 screws to remove the IO BOX Cover.

Figure 8-160 Screw points of IO BOX cover
