GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 5 - Components and Functions (Theory) 5-41

5-11-5 Advanced Information - Service Desktop and SSA (Secure Service Access)

SSA Key

The SSA key provides secure access for GE service personnel to advanced tools to service the system

• Access to all service features

• Access to Windows Desktop

• Key must be renewed every 30 days

• Tied to SSO

• Password locked via key pad

Figure 5-26 SSA Key

Item Description

1. Blue LED

2. Key Pad

3. Lock Indicators
