5-32 Section 5-10 - Common Service Desktop (CSD) (R1, R2, R2.5 only)

5-10-6 Configuration

In the Configuration page, you can view and modify different device informations and configurations.

in the “InsiteExC Agent Configuration” option field.

Figure 5-21 Common Service Desktop - Configuration

NOTICE

!! NOTICE:

Remote access is ONLY possible if the service platform is properly configured (either by the user

or a GE technician at site). Operation see: Section 7-5-6 "CSD: Configuration" on page 7-18.
