GE
DRAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019
)
S
ERVICE
M
ANUAL
Chapter 8 -
Replacement Pr
ocedures
8-89
8-14-3-6
Removal Procedure -
Freeze key a
ssy
1)
Remove connector as following figure
Figure 8-87 Disconnectio
n of freeze key
Assy connector
2)
Remove 3 screws fr
om Freeze key Assy
Figure 8-88 Screw points of free
ze key assy .
3)
Slowly lift board from OP Panel.
414
416
