GE
RAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019)
S
ERVICE
M
ANUAL
8-88
Section 8-14 - Re
placement of OPIO and Relate
d Parts
8-14-3-5
Removal Procedure - LCD Touch Panel Assy
1)
Disconnect connectors as following figure.
Figure 8-85 Disconnect
ion of LCD T
ouch panel
Assy
2)
Remove 4 screws as following figure.
Figure 8-86 Removal of 4 screws of LCD T
ouch panel
Assy
413
415
