GERAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

8-126 Section 8-22 - Replacement of Caster

6) Remove Nut and replace Caster.

Figure 8-150 Removable Nut of Caster

8-22-4 Installation Procedure

Parts to be installed in reverse order of removal.

NOTE: Hex screws should be tightened.

8-22-5 Functional Check

Visual inspection Only.

CAUTION

!! CAUTION:

Proceed with extreme caution and avoid system tipping over. The system weighs

approximately 60kg.
