GE
DRAFT
LOGIQ P9/P7
D
IRECTION
5604324
, R
EVISION
11
DRAFT
(J
ANUARY
24, 2019
)
S
ERVICE
M
ANUAL
Chapter 4 - Func
tional Checks
4-7
4-3-2
Mechanical Parts Functional Check
Figure 4-4 System Mechanic
al Checkpoint
CAUTION
!! CAUTION:
Pay attention to
moving parts and pinch point
wh
en perfo
rming mechanical parts
functional
check.
Location
1
Main LCD
2
OPIO Swivel Lock
3
OPIO UP_DOWN Lock
4
Total Lock Caster
5
Swivel-Lock Caster
6
LCD Arm
146
