FRONT WHEEL/SUSPENSION/STEERING
Remove the cap.
Remove the steering stem nut [1].
Remove the fork legs (page 17-25).
Release the following:
– Clutch cable (NC700X/XA) [1]
– Parking brake cable (NC700XD) [1]
– Left handlebar switch wire harness clamp [2]
– Throttle cables [3]
– Right handlebar switch wire harness clamp [4]
– Brake hose [5]
Remove the top bridge [6].
NC700XA/XD/SA/
SD:
Remove the bolt [1], front wheel speed sensor wire
guide [2] and brake hose joints [3].
Straighten the lock washer tabs [1].
Remove the steering stem adjusting lock nut [2] and
lock washer.
[1]
NC700X/XA/XD:
[1] [5] [3][2]
[4]
[6]
[1] [3]
[2]NC700XA/XD/SA/SD:
[2]
[1]
[1]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
