Basic copy operations
2
C451 2-93
Punching holes in copies (Punch settings)
!
Detail
In order for holes to be punched in the copies on the finisher FS-517/FS-
608, all of the following conditions must be met.
- The paper width must be between 182 mm and 297 mm.
- The paper length must be between 182 mm and 432 mm.
If a Punch setting is to be selected, select the orientation in which the
document is positioned. If an Original Direction setting is not selected,
holes may not be punched in the copies as desired.
For details on specifying the document orientation, refer to “Selecting the
document orientation (Original Direction settings)” on page 2-29.
2
Note
The Punch settings are available only if the punch kit is installed on the
optional finisher.
The number of punched holes differs depending on the country (region)
where the unit is installed. For details, consult your service representa-
tive.
When Finisher FS-517/FS-608 is installed
* There are five Foolscap sizes: 220 × 330 mm w, 8-1/2 × 13 w, 8-1/4 × 13 w, 8-1/8 × 13-1/4 w,
and 8 × 13 w. Any one of these sizes can be selected. For details, contact your service repre-
sentative.
When Finisher FS-519 is installed
Tray Paper weight Paper size
Finishing
Tray 1
64 g/m
2
to 128 g/m
2
“2-Hole” Punch setting:
A3 w to A5 v/w, 11 × 17 w to 5-1/2 × 8-1/2 w,
8 × 13 w*, 8K w, 16K v/w
“3-Hole”/“4-Hole” Punch setting:
A3 w, B4 w, A4 v, B5 v, 11 × 17 w, 8-1/2 × 11 v,
7-1/4 × 10-1/2 v, 8K w, 16K v
Paper weight Paper size
64 g/m
2
to 209 g/m
2
A3 w, A4 v, B5 v
To Next Page
