Troubleshooting
4
C451
4-12
Clearing a paper misfeed in
the ADF
(transport section)
!
Detail
For details on the positions of paper
misfeeds, refer to
“Paper misfeed in-
dications” on page
4-5.
1
Remove a
ll docume
nt
pages remaining in the
document feed
tray.
2
Open the lef
t-side cover.
281
283
