Before making copies
1
C451 1-19
Finisher FS-519
Output tray OT-602
Punch kit PK-515
* Parts marked with an asterisk are internal options and therefore are not shown in the illustration.
No. Part name Description
1 Output tray 1 Collects printed pages.
2 Output tray 2 Collects printed pages.
3 Misfeed-clearing dial FN6 Turned when clearing paper misfeeds within the fin-
isher.
4 Misfeed-clearing dial FN5 Turned when clearing paper misfeeds within the fin-
isher.
5 Misfeed-clearing dial FN4 Turned when clearing paper misfeeds within the fin-
isher.
6 Misfeed-clearing dial FN2 Turned when clearing paper misfeeds within the fin-
isher.
7 Guide lever FN1 Raised when clearing paper misfeeds within the fin-
isher.
8 Punch scrap box FN3.1 Removed when emptying punch scraps that have
accumulated from using the Punch settings.
9 Guide lever FN3 Raised when clearing paper misfeeds within the fin-
isher.
10 Stapler Moved to the front when clearing jammed staples.
11 Staple cartridge holder Removed from the stapler when replacing the staple
cartridge or clearing jammed staples.
12 Dial Turned to move the stapler to the front when clearing
jammed staples.
13 Finisher release lever 1 Used to disconnect the finisher and move it from the
main unit when clearing paper misfeeds.
No. Part name Description
14 Optional output tray Collects printed pages.
No. Part name Description
15 Punch kit* Punches holes for filing printed pages when the
punch kit is installed onto finisher FS-519.
