Utility mode
11
C451 11-90
9 Check the print result.
– Check that the angle of the punched holes was adjusted.
– If more adjustment is necessary, repeat steps 6 and 7.
Punch Edge Sensor Adjustment
The sensors for detecting the paper edges when printing with a Punch
setting can be adjusted.
2
Note
[Punch Edge Sensor Adjustment] appears only if optional punch kit is in-
stalled on finisher FS-517 or FS-608.
For details on the Punch settings, refer to “Punching holes in copies
(Punch settings)” on page 2-93.
1 Display the Administrator Settings screen.
– For details on displaying the Administrator Settings screen, refer to
“Displaying the Administrator Settings screen” on page 11-56.
2 Touch [1 System Settings].
The System Settings screen appears.
3 Touch [7 Expert Adjustment].
The Expert Adjustment screen appears.
4 Touch [3 Finisher Adjustment].
The Finisher Adjustment screen appears.
To Next Page
