- 338 -
9. Operating Management/ Specifications
• Network Setup
• Mail Server Setup
• LDAP Server Setting
• Secure Protocol Server Setting
Network Setup
• Network Setting
Network Menu
Item Factory default setting Description
Enabling Default Gateway Wired Sets which default gateway to be enabled
between wired LAN or wireless LAN.
Wired Enable Sets whether to enable wired LAN.
TCP/IP Enable Sets whether to enable TCP/IP.
NetBIOS over TCP Enable Sets whether to enable NetBIOS over TCP/
IP.
This item is displayed when TCP/IP protocol
is enabled.
IP Address Set Auto Sets the method of assigning an IP address.
IPv4 Address 192.168.100.100 Sets an IP address.
This item is displayed when TCP/IP protocol
is enabled.
Subnet Mask 255.255.255.0 Sets a subnet mask.
This item is displayed when TCP/IP protocol
is enabled.
Gateway Address 0.0.0.0 Sets a gateway address.
This item is displayed when TCP/IP protocol
is enabled.
DHCPv6 Disable Selects enable / disable of DHCP when IPv6
is used.
DNS Server (Primary) 0.0.0.0 Sets the IP address for a Primary DNS
server.
This item is displayed when TCP/IP protocol
is enabled.
DNS Server (Secondary) 0.0.0.0 Sets the IP address for a Secondary DNS
server.
This item is displayed when TCP/IP protocol
is enabled.
WINS Server (Primary) 0.0.0.0 Sets the name or the IP address for the
WINS server.
This item is displayed when TCP/IP protocol
is enabled.
WINS Server (Secondary) 0.0.0.0 Sets the name or the IP address for the
WINS server.
This item is displayed when TCP/IP protocol
is enabled.
Proxy Disable Sets whether to use proxy.
Proxy Server (NULL) Sets the name or IP address of the proxy
server. You can enter up to 15 characters.
Proxy Server Port No. 8080 Sets the port number of the proxy server.
Proxy User ID (NULL) Sets the user ID to connect to the proxy
server.
Proxy Password (NULL) Sets the password to connect to the proxy
server.
Web Enable Sets whether to enable access from a Web
browser.
This item is displayed when TCP/IP protocol
is enabled.
Telnet Disable Sets whether to enable access from the
Tel n et.
This item is displayed when TCP/IP protocol
is enabled.
FTP Disable Sets whether to enable access with FTP.
This item is displayed when TCP/IP protocol
is enabled.
IPSec Disable This item is displayed only if IPSec is set to
valid. This item can be changed to disable
only.
SNMP Enable Sets whether to enable access from SNMP.
This item is displayed when NetWare or TCP/
IP protocol is enabled.
Network Scale Normal [Normal]: The machine operates effectively
even if connected to a HUB with the
spanning tree function. However, the
machine takes longer to start up if it is
connected to a small LAN that consists of two
or three computers.
[Small]: This setting covers a small LAN that
consists of two or three computers to a large
LAN, but the machine may not operate
efficiently if it is connected to a HUB with the
spanning tree function.
Item Factory default setting Description
To Next Page
