Reading 2D-codes
FQ2-S4 User’s Manual
4
Setting Up Inspections
125
Reflect in Total Judgement
You can specify whether to reflect the verification result of a 2D code inspection item in the overall judgement.
(The default setting is [Yes].)
[Inspect] − [Inspection] − [Add item.] − [2D-code] − [Details] Tab Page − [Output parameter] −
[Reflect]
Detail Settings
With the default settings, all of the parameters are set automatically. If the automatic settings are incorrect for
any reason, e.g., the code was read incorrect, set the detailed parameters manually and then perform teaching.
[Inspect] − [Inspection] − [Add item.] − [2D-code] − [Details] Tab Page
Press [Meas. Parameter]
Set the measurement parameters.
Be sure to always specify the code type. When you automatically register matrix data, the code type, code
color, data matrix shape, and reverse settings are set automatically.
Outputting Read Characters to an External Device
After a measurement, you can automatically output the character string that was read with the 2D-code
inspection item to a PLC or other external device. The character strings are output after outputting the output
data (output data settings 0 to 31), such as the inspection item parameters and calculation result.
Refer to the description for the communications format for the setting procedure and output specifications to
output the character string.
Outputting Character Strings
• EtherNet/IP: p. 346
• PLC Link: p. 383
• TCP No-protocol Communications: p. 408
Setup Item Setting Value Description
Code type Data Matrix (Default) Selects the type of 2D Code to be read.
QR Code
MicroQR Code
PDF417
MicroPDF417
Reverse Normal (default value) Sets normal or reverse as the image orientation.
This parameter is valid only one of the following code types is selected.
Data Matrix, QR Code, or Micro QR Code
Reverse
Code color Black Specifies the code color.
This item is enabled only when the following barcode types are selected:
Data Matrix, QR Code, MicroQR Code
White
Auto (default value)
Shape (Data Matrix) Square (default value) Specifies the code shape.
This item is enabled only when the following barcode types are selected:
Data Matrix
Square or Rectangle
Timeout 1 to 9999 ms
(default value: 9999)
Sets the timeout time in read processing. A read error occurs if measure-
ment does not end after the preset timeout time is exceeded.
To Next Page
