Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
432
FQ2-S4 User’s Manual
List of FINS Commands
Command List
The following table lists the FINS commands.
Commands that can be used in FINS Ethernet communications are listed below.
Type of command Command codes (hex) Function Reference
MRC+SRC com-
mand code
Vision Sensor com-
mand code
Measurement control
and measurement
acquisition commands
280F 00101010 Executes one measurement. p.433
Utility commands 280F 00102010 Clears the measurement values. p.434
280F 00102040 Clears the error output status (error signal and
error indicator).
p.434
280F 00103010 Saves the settings data to the Sensor. p.435
280F 00104010 Re-registers the models for registered Search
and Color Data inspection items.
p.435
280F 0010F010 Restarts the Sensor. p.436
280F 00104020 Executes teaching for all applicable inspection
items.
p.436
Scene control com-
mands
280F 00201000 Acquires the current scene number. p.437
280F 00301000 Changes the scene number being used. p.438
Data acquisition/setting
commands
280F 00401010 Acquires image adjustment data p.439
280F 00501010 Sets image adjustment data. p.440
280F 00401020 Acquires the inspection item data. p.441
280F 00501020 Sets the inspection item data. p.442
280F 00403000 Acquires the version information of the Sensor
software.
p.443
280F 00205000 Acquires the latest error code of the Sensor. p.443
To Next Page
