Menu Tables
474
FQ2-S4 User’s Manual
In/Out Tab Page
Calculation
Settings
Expression
[MENU]
Expression 0 to
expression 31
Sets the number of the expression for
which to set a calculation.
--- Scene p. 199
Expression set-
tings
Sets the expressions. --- Scene
Data Uses the measurement result of other
items.
Inspection item, calculation symbols ( ( )
/ * . , + TJG)
Scene p. 204
Const. Inputs constants or mathematical
operators.
0 to 9, ., calculation symbol ( ( ) / * ? , +
TJG)
Scene p. 199
Math. Uses functions in expressions. SIN, COS, ATAN, AND, OR, NOT, ABS,
MAX, MIN, MOD, SQRT, ANGL (angle
of straight line joining two points (center
of gravity and model center)), DIST (dis-
tance between two points), calculation
symbols ( ( ) / * . , + TJG)
Scene p. 201
Rename Deletes/copies the expression or
changes the expression name.
--- Scene p. 199
Copy --- Scene
Delete --- Scene
Judgement Specifies the parameters for judge-
ment of results.
Scene p. 203
Details
Output parameter
Reflect You can specify whether to reflect the
judgement results of a calculation in
the overall judgement.
No, Yes (default), Scene p. 203
Retry details
Max Count
(Normal retry)
Sets the number of retries.
0 to 8, Default: 4 Scene
Interval
(Normal retry)
Sets the retry interval (msec).
32 to 999, Default: 100 Scene
Brightness step or Shutter
speed step
(Exposure retry)
Sets the exposure time step (msec). Brightness step:
1 to 20, Default 2
shutter speed step:
0.01 to 1.00 (Default: 1.00)
Scene
Increment count
(Exposure retry)
Sets the increment count for the
brightness (shutter speed) step.
0 to 10, 2 (default) Scene
Decrement count
(Exposure retry)
Sets the decrement count for the
brightness (shutter speed) step.
0 to 10, 2 (default) Scene
Menu command Description Setting range Data Refer-
ence
Log setting
Statistical data Sets whether to record the number of
measurements and the number of NG
overall judgements.
ON (default) or OFF System p. 258
Image logging Sets the parameter to log measurement
image data.
All, Only NG, or None (default) System p. 253,
p. 258
Data log-
ging
Condition Sets the parameter to log measurement
data from inspection items.
All, Only NG, or None (default) System p. 253
Select data You can select the parameters to log
from the parameters in the filter items,
position compensation items, inspection
items and expression that are set.
Parameter names for the filter items,
position compensation items, inspection
items and expression that are set
System p. 253
Delete Log Resets the log data without turning OFF
the power supply.
--- System p. 260
Menu command Description Setting range Data Refer-
ence
