Omron FQ2-S4 User Manual

External Reference Parameters
502
FQ2-S4 User’s Manual
Two-edge Position Compensation
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not
measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not per-
formed error,
−14: Figure not registered
error,
−15: Out of range error
−2 JG Logged data
5 Scroll X Acquisition
only
−99,999.9999 to
99,999.9999
0 DX Logged data
6 Scroll Y Acquisition
only
−99,999.9999 to
99,999.9999
0 DY Logged data
7 Detected edge position
X0
Acquisition
only
−99,999.9999 to
99,999.9999
0 X0 Logged data
8 Detected edge position
Y0
Acquisition
only
−99,999.9999 to
99,999.9999
0 Y0 Logged data
9 Detected edge position
X1
Acquisition
only
−99,999.9999 to
99,999.9999
0 X1 Logged data
10 Detected edge position
Y1
Acquisition
only
−99,999.9999 to
99,999.9999
0 Y1 Logged data
11 Standard position X0 Acquisition
only
−99,999.9999 to
99,999.9999
0 SX0 Logged data
12 Standard position Y0 Acquisition
only
−99,999.9999 to
99,999.9999
0 SY0 Logged data
13 Standard position X1 Acquisition
only
Å|99,999.9999 to
99,999.9999
0 SX1 Logged data
14 Standard position Y1 Acquisition
only
−99,999.9999 to
99,999.9999
0 SY1 Logged data
103 Output
parame-
ter
Reflect Setting/Acqui-
sition
0: Yes, 1: No 0 --- ---
