Logging Measurement Data and Image Data
252
FQ2-S4 User’s Manual
7-6 Logging Measurement Data and Image Data
There are two ways to log data.
Recent results logging: Data is temporarily saved in memory inside the Sensor.
File logging: Large amounts of data are saved in SD cards or other external media.
The amounts and types of data that can be logged depend on the logging method that is used, as shown in the
following table.
*1 For recent results logging, the oldest data is overwritten when the maximum number of saved data items is exceeded.
*2 This limit is for one data item.
If more than one data item is logged at the same time, logging can be performed as long as the total number of data items in all logged
data is 32,000 or less.
Logging Procedure
Use the following procedure to log data.
Logged data Logged quantity
Recent results logging
*1
File logging
Statistical data One value (The average value of the mea-
surement results in the collected measure-
ment data is continuously updated.)
Not possible.
Measurement data 1,000 measurement values max.
*2
Up to the capacity of the external memory
Image data 20 images max.
Logging settings
(common settings for recent results logging and file logging)
Output settings
(common settings for recent results logging and file logging)
• Setting the File Name for Logged Data
• Setting the Format for Saving Measurement Data
Execution of file logging
(Change to Run Mode.) (Change to Run Mode.)
• Enabling File Logging
• Starting and Stopping Logging
• Saving Recent Results Logging Data
• Deleting Logged Data
Enabling file logging
Executing file logging.
• Setting Logging Conditions
• Selecting the Measurement Data To Log
Execution of recent
results logging
File logging: p. 253
Recent results logging: p. 258
p. 254
p. 255
p. 256
p. 256
p. 257
p. 260
p. 260
To Next Page
