Inspecting with the Edge Position Inspection Item
FQ2-S4 User’s Manual
4
Setting Up Inspections
167
Increasing Processing Speed for Edge Position
Make the measurement region smaller to reduce the processing time.
Changing the measurement region: p. 144
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via the Ethernet or used
in calculations.
4-17 Calculations and Judgements Using Inspection Item Data: p. 197
Measurement Data That Can Be Logged for Edge Position
The following values can be logged as measurement data.
* When logging data is output, the data is output in the order of the above table.
If more than one item is stored, results are output for each model.
7-6 Logging Measurement Data and Image Data: p. 252
Expression text string Data name Description Data range
JG Judgement This is the judgement result. −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
X Position X This is the X coordinate of the mea-
sured edge position.
−99999.9999 to 99999.9999
Y Position Y This is the Y coordinate of the mea-
sured edge position.
−99999.9999 to 99999.9999
SX Ref. position X (reference
position X)
This is the X coordinate of the edge
position when a range is set.
−99999.9999 to 99999.9999
SY Ref. position Y (reference
position Y)
This is the Y coordinate of the edge
position when a range is set.
−99999.9999 to 99999.9999
DF D. position (difference in
position)
This is the offset from the measured
reference position.
−99999.9999 to 99999.9999
Measured item Range of value Description
Judgement 0: Judgement is OK
−1: Judgement is NG
−13: Teaching not performed error
−14: Figure not registered error
−15: Out of range error
This is the measurement judgement results.
D. position (difference in
position)
−893 to 893 This is the offset from the measured reference position.
Position X −99999.9999 to 99999.9999 This is the X coordinate of the measured edge position.
Position Y −99999.9999 to 99999.9999 This is the Y coordinate of the measured edge position.
