Inspecting with the Labeling Inspection Item
FQ2-S4 User’s Manual
4
Setting Up Inspections
195
Increasing the Processing Speed
Make the measurement region smaller to reduce the processing time.
Changing the Measurement Region p. 144
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via the Ethernet or used
in calculations.
4-17 Calculations and Judgements Using Inspection Item Data p. 197
Expression text
string
Data name Description Data range
JG Judgement This is the Labeling judgement results. −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
L Number of labels This is the number of labels found. 0 to 100
TAR Total label area This is the total area of all labels found. 0 to 999,999,999.9999
AR[0] to AR[99] Area These are the areas of each individual label. 0 to 999,999,999.9999
X[0] to X[99] Gravity X These are the X coordinates of the center of
each label.
−99,999.9999 to 99,999.9999
Y[0] to Y[99] Gravity Y These are the Y coordinates of the center of
each label.
−99,999.9999 to 99,999.9999
ATH[0] to ATH[99] Master angle These are the master angle of the center of each
label.
−180 to 180
SA Reference area This is the reference area. 0 to 999,999,999.9999
SX Ref. position X (refer-
ence position X)
This is the X coordinate of the reference posi-
tion.
−99,999.9999 to 99,999.9999
SY Ref. position Y (refer-
ence position Y)
This is the Y coordinate of the reference posi-
tion.
−99,999.9999 to 99,999.9999
To Next Page
