External Reference Parameters
542
FQ2-S4 User’s Manual
Area
310 Logging
condi-
tions
Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
312
Data logging switch
for edge pitch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
313
Data logging switch
for average pitch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
314
Data logging switch
for maximum pitch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
315
Data logging switch
for minimum pitch
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
316
Data logging switch
for average width
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
317
Data logging switch
for maximum width
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
318
Data logging switch
for minimum width
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
700 Display
settings
Edge pitch display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
701 Average pitch display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
702 Pitch display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
703 Average width display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
704 Width display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
External
reference
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0 Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not mea-
sured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed
error,
−14: Figure not registered error,
−15: Out of range error
−2 JG ---
5 Area Acquisition
only
0 to 999,999,999.9999 0 AR ---
11 Area deviation Acquisition
only
−999,999,999.9999 to
999,999,999.9999
0 DF Logged data
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
