Functions Related to the System
278
FQ2-S4 User’s Manual
Checking the Touch Finder Battery Level
(Setup Mode or Run Mode) − [TF settings] − [Battery level]
• The battery level is displayed only for a Touch Finder with a DC/AC/battery power supply (FQ2-D31).
• The settings will be lost if the battery runs out while you are making the settings. If the battery level is low,
save the settings and charge the battery immediately.
Changing the Sensor Name
An alphanumeric name can be assigned to a Sensor to make it easier to recognize. This is convenient when
more than one Sensor is connected.
(Setup Mode) − [Sensor settings] − [Information] − [] − [Rename]
Checking Available Memory in the Sensor
If a setting cannot be made, check the amount of memory that is available in the Sensor.
(Setup Mode) − [Sensor settings] − [Information] − [] − [Memory state]
Correcting the Touch Screen Positions of the Touch Finder
Use this function to correct the touch screen positions if they are offset from the opposite position.
(Setup Mode) − [TF settings] − [Touch screen calib]
Setting the Resolution of Measurement Objects Displayed on the PC Tool
Use this function to set the resolution of measurement object that are displayed on the Touch Finder on the
computer.
(Run Mode) − [TF settings] − [Resolution]
Rotating the Touch Finder Image by 180°
You can rotate the Camera image by 180°.
This setting applies to logged images as well.
[Image] − [Camera setup] − [] − [Rotate 180]
Changing the Sensor’s BUSY Indicator
You can change the BUSY indicator to a RUN indicator.
[In/Out] − [I/O setting] − [I/O setting] − [Output] − [BUSY LED]
Setting the Inspection Timeout Time
The time after which inspection times out can be set (msec).
(Run Mode) − [Sensor settings] − [Timeout]
Important
