Menu Tables
490
FQ2-S4 User’s Manual
Common Menu Commands
Sensor monitor
Multi sensor Simultaneously displays the images for
multiple connected Sensors.
--- --- p. 227
NG sensor From multiple connected Sensors, dis-
plays the image of only the Sensors with
NG results.
--- ---
Switch sensor
Select Switches to the selected Sensor. --- --- p. 58
Connections Displays the name of the Sensor
detected by the Touch Finder and the
connection status.
---
Auto con-
nect
Automatically detects and connects the
Sensors that are connected.
---
Menu command Description Setting range Data Refer-
ence
Only-image Button Hides text and displays only the image. --- --- p. 246
Dis-
play
Button
Zoom-in
Button
Enlarges the image display. --- --- p. 244
Zoom-out
Button
Reduces the image display.
FIT Button Fits the image to the display size.
Display But-
ton
Changes the image display method. Setup Mode: Camera (Live, Freeze) Log,
Logging image file or Camera image file
Run Mode: Latest image or Last NG
---
Log Image
Button
You can save the Camera image that is
displayed on the Touch Finder or com-
puter.
--- --- p. 245
Capture Button Used to capture the current display and
save it in external memory, e.g., an SD
card.
--- --- p. 268
Menu command Description Setting range Data Refer-
ence
