Omron FQ2-S4 User Manual

External Reference Parameters
FQ2-S4 User’s Manual
497
Appendices
12
Search Position Compensation
700 Display
settings
Position compensation
X display
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
701 Position compensation
Y display
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
702 Theta position compen-
sation display
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
703 Correlation display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
704 Position X display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
705 Position Y display Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
706 Measurement angle
display
Setting/Acqui-
sition
0: Display, 1: Do not display 0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not mea-
sured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed
error,
−14: Figure not registered error,
−15: Out of range error
−2 JG Logged data
5 Scroll X Acquisition
only
−99,999.9999 to 99,999.9999 0 DX Logged data
6 Scroll Y Acquisition
only
−99,999.9999 to 99,999.9999 0 DY Logged data
8 Position X Acquisition
only
−99,999.9999 to 99,999.9999 0 X Logged data
9 Position Y Acquisition
only
−99,999.9999 to 99,999.9999 0 Y Logged data
11 Reference X Acquisition
only
−99,999.9999 to 99,999.9999 0 SX Logged data
12 Reference Y Acquisition
only
−99,999.9999 to 99,999.9999 0 SY Logged data
14 Correlation Acquisition
only
0 to 100 0 CR Logged data
103 Output
parame-
ter
Reflect Setting/Acqui-
sition
0: Yes, 1: No 0 --- ---
120 Mea-
sure-
ment
condi-
tions
Position compensation
precision
Setting/Acqui-
sition
0: None, 1: Bilinear 0 --- ---
122 Position compensation
Setting/Acqui-
sition
0: Camera image,
1: Previous image
0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
