Menu Tables
458
FQ2-S4 User’s Manual
12-1 Menu Tables
Image Tab Page
Menu command Description Setting range Data Refer-
ence
Camera setup
Focus The value shown here is used as a refer-
ence when adjusting the focus with the
focus adjustment screw.
--- --- p. 60
Image mode Pixel sampling can be applied to the
input image to reduce image input time.
Normal (default) or Fast Scene p. 218
Shutter speed
(Normal mode)
Sets the shutter speed for Normal Mode. FQ2-S4@-@@@
1/1 to 1/60,000
FQ2-S4@@@@@-08@
1/1 to 1/60,000
1/250 to 1/60,000 (for Sensors with
Built-in Lighting)
FQ2-S4@@@@ or FQ2-S4@@@@-M
1/1 to 1/50,000
1/250 to 1/50,000 (for Sensors with
Built-in Lighting)
Default: 1/250
Scene p. 63
Gain
(Normal mode)
If the gain is high, the image will be
bright. If the gain is low, the image will be
dark.
For FQ2-S4@@@@@-08@,
FQ2-S4@-@@@
Range: 0 to 10 (default: 10)
For FQ2-S4@@@@@@,
FQ2-S4@@@@@@-M
Range: 16 to 64 (default: 16)
Scene p. 63
Brightness
(HDR mode)
Sets the brightness level of the image for
HDR Mode.
1 to 100 Scene p. 63
HDR Suppresses reflections and differences
in brightness.
OFF(default), Level 1 to Level4 Scene p. 65
Brightness correc-
tion
Use to stabilize the brightness. ON or OFF (default) Scene p. 66
White balance Corrects differences in coloring between
the image and the actual object.
•AUTO
• R: 0.001 to 7.999
• G: 0.001 to 7.999
• B: 0.001 to 7.999
Scene p. 66
Partial input Used to make the image input range
smaller.
FQ2-S4@@@@@/FQ2-S4@@@@@-M:
752×8 to 752×480
FQ2-S4@@@@@@-08@:
928×8 to 928×828
FQ2-S4@-@@@: 1280×8 to
1280×1024
Scene p. 217
Rotate 180 You can rotate the Camera image by
180°.
ON or OFF (default) Scene p. 278
Calibration setting Sets a registered calibration pattern. Unregistered (default), New Calibra-
tion, or Calibration Data 0 to 31
Scene p. 243
Lightning control
Strobe output delay Sets the delay time for the strobe output
signal (STGOUT) in response to the trig-
ger signal.
0 to 65,535 µs (default: 0 µs) Scene p. 316
Strobe output time Sets the output time of the strobe output
signal (STGOUT).
0 to 65,535 µs (default: 1,000 µs) Scene p. 316
Trigger setup
Trigger delay Adjusts the time until the Camera shutter
opens after the trigger signal is received.
0 to 163 ms (default: 0) System p. 67
To Next Page
