Omron FQ2-S4 User Manual

External Reference Parameters
516
FQ2-S4 User’s Manual
2D Codes (DPM)
External
refer-
ence
number
Category Data name Set/acquired Data range Default Text string
assigned
to
Ethernet
output
setting
Logged
0 Mea-
sure-
ment
result
Judgment Acquired only
-2: No judgment (not
inspected)
0: Judgment result OK
-1: Judgment result NG
-13: Teaching not executed
error
-14: Figure not registered
error
-15: Outside region error
-16: Inspection timeout
error
-2 JG
Logged
5 Num. of char. Acquired only 0 to 1024 0 N Logged
6
*1
Characters Acquired only Text string --- --- ---
8 Cell Recog. Rate Acquired only 0 to 100 0 E Logged
9 Contrast Acquired only 0 to 100 0 C Logged
10 Focus Acquired only 0 to 100 0 F ---
17 Index number Acquired only -2: Verification OFF or read-
ing error, -1: Verification is
NG, 0 to 31: Master data
No.
−2IN
Logged
103 Output
parame-
ter
Reflect Setting/Acqui-
sition
0: Yes, 1: No 0 --- ---
