Omron FQ2-S4 User Manual

Controlling Operation and Outputting Data with TCP No-protocol Communications
FQ2-S4 User’s Manual
411
Connecting through Ethernet
9
Command List
The following table lists the no-protocol commands.
Commands that can be used in no-protocol Ethernet communications are listed below.
Type of command Command Abbreviation Function Reference
Measurement control
and measurement acqui-
sition commands
MEASURE M Executes one measurement. p. 412
MEASURE /C M /C Starts continuous measure-
ments.
p. 413
MEASURE /E M /E Ends continuous measure-
ments.
p. 414
Utility commands CLRMEAS None Clears the measurement val-
ues.
p. 415
CLRERR None Clears the error output status
(error signal and error indica-
tor).
p. 416
DATASAVE None Saves the settings data to the
Sensor.
p. 416
MODEL None Re-registers the models for
registered Search inspection
items.
p. 417
RESET None Restarts the Sensor. p. 417
TEACH None Executes teaching for all
applicable inspection items.
p. 418
Scene control com-
mands
SCENE S Acquires the current scene
number.
p. 418
SCENE Scene_number S Scene_number Changes the scene number
being used.
p. 419
Data acquisition/setting
commands
POSITIONDATA
Item_number
External_reference_data_nu
mber
PD
Item_number
External_reference_data_nu
mber
Acquires data from a position
compensation item or filter
item.
p. 420
POSITIONDATA
Item_number
External_reference_data_nu
mber Setting
PD
Item_number
External_reference_data_nu
mber Setting
Sets data for a position com-
pensation item or filter item.
p. 420
ITEMDATA
Inspection_item_number
External_reference_data_nu
mber
ID Inspection_item_number
External_reference_data_nu
mber
Acquires the inspection item
data.
p. 422
ITEMDATA
Inspection_item_number
External_reference_data_nu
mber Set_value
ID Inspection_item_number
External_reference_data_nu
mber Set_value
Sets the inspection item data. p. 423
ITEMDATA2
Inspection_item_number
External_reference_data_nu
mber
ID2 Inspection_item_number
External_reference_data_nu
mber
Acquires the text string data
of the specified inspection
item.
p. 424
ITEMDATA2
Inspection_item_number
External_reference_data_nu
mber
Text_strings
ID2 Inspection_item_number
External_reference_data_nu
mber
Text_strings
Sets the text string data of the
specified inspection item.
p. 425
VERGET/S None Acquires the version informa-
tion of the Sensor software.
p. 426
VERGET/H None Acquires the Sensor model
information.
p. 427
ERRGET None Acquires the latest error code
of the Sensor.
p. 428
