Inspecting with the Edge Pitch Inspection Item
176
FQ2-S4 User’s Manual
Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be output to external devices or used in calculations as measurement data.
4-17 Calculations and Judgements Using Inspection Item Data: p. 197
Measurement Data That Can Be Logged for Edge Pitch
The following values can be logged as measurement data.
* When logging data is output, the data is output in the order of the above table.
7-6 Logging Measurement Data and Image Data: p. 252
Errors
Errors in Teaching
A teaching error message will appear if the edge pitch cannot be detected when teaching. Perform the
following.
• If the color of the measurement object has changed from the specified color, set the color again and try
teaching again.
Expression text string Data name Description Data range
JG Judgement This is the judgement result. −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
N Edge pitch This is the number of objects. 0 to 999
P Average pitch This is the average pitch. 0 to 99999.9999
PH Max. pitch This is the maximum pitch. 0 to 99999.9999
PL Min. pitch This is the minimum pitch. 0 to 99999.9999
W Average width This is the average width between
edges.
0 to 99999.9999
WH Max. width This is the maximum width between
edges.
0 to 99999.9999
WL Min. width This is the minimum width between
edges.
0 to 99999.9999
Measured item Range of value Description
Judgement −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error
This is the judgement result from the measurements.
Edge pitch 0 to 999 This is the number of objects that were detected.
Average pitch 0 to 99999.9999 This is the average pitch that was detected.
Max. pitch 0 to 99999.9999 This is the maximum pitch that was detected.
Min. pitch 0 to 99999.9999 This is the minimum pitch that was detected.
Average width 0 to 99999.9999 This is the average width that was detected between edges.
Max. width 0 to 99999.9999 This is the maximum width that was detected between edges.
Min. width 0 to 99999.9999 This is the minimum width that was detected between edges.
To Next Page
