Convenient Functions for Operation
268
FQ2-S4 User’s Manual
Capturing the Displayed Image
The current display on the Touch Finder or PC Tool can be captured and used in text files and other files on the
computer.
The captured images are saved in external memory
*1
as bit maps.
*1: Images captured on the Touch Finder are saved in the SD card. Images captured with the PC Tool are saved in the computer’s hard disk drive.
(Setup Mode or Run Mode)
The image that is being displayed when the button is pressed is saved in external memory.
• Storage Location and File Names
Make sure an SD card is inserted in the Touch Finder before capturing display images.
Saving the Currently Displayed Camera Image
You can save the Camera image that is displayed on the Touch Finder or computer.
(Setup Mode) − − (Log Image Button)
The Camera image that is being displayed when the Button is pressed is saved in external memory.
• Storage Location and File Names
Make sure an SD card is inserted in the Touch Finder before capturing display images.
Storage location File name
\CAPTURE YYYY_MM_DD-HH_MM_SS_MS.BMP
Example: The following name would be used for an image that was captured at
10:10:21.350 pm on March 10, 2010.
For the PC Tool, data will be saved in the following folder: \\..\My Documents\OMRON FQ
Storage location File name
\CAPTURE YYYY_MM_DD-HH_MM_SS_MS.IFZ
Example: The following name would be used for an image that was captured at
10:10:21.350 pm on March 10, 2010: 2010_03_10-22_10_21_350.IFZ
For the PC Tool, data will be saved in the following folder: \\..\My Documents\OMRON FQ
Important
Note
Important
Note
