External Reference Parameters
FQ2-S4 User’s Manual
491
Appendices
12
12-2 External Reference Parameters
Color Gray Filter
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not mea-
sured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed
error,
−14: Figure not registered error,
−15: Out of range error
−2JG ---
120 Mea-
sure-
ment
condi-
tions
Source image Setting/Acqui-
sition
0: Camera image,
1: Previous image
1 --- ---
121 Setting method Setting/Acqui-
sition
0: Filtering OFF, 1: Filtering ON 1 --- ---
122 Filter type Setting/Acqui-
sition
Filter type
0: RGB
1: HSV
0 --- ---
123 Color filter type Setting/Acqui-
sition
Color Filter Type
0: Red filter,
1: Green filter,
2: Blue filter,
3: Cyan filter,
4: Magenta filter,
5: Yellow filter,
6: Gray filter (R+G+B),
7: Gray filter (R+2G+B),
8: Gray filter (user-set),
0 --- ---
124 Color gray filter type Setting/Acqui-
sition
Color Gray Filter Type
0: High speed, 1: High precision
1 --- ---
125 RGB gain R Setting/Acqui-
sition
0.0001 to 9.9999 0.3 --- ---
126 RGB gain G Setting/Acqui-
sition
0.0001 to 9.9999 0.59 --- ---
127 RGB gain B Setting/Acqui-
sition
0.0001 to 9.9999 0.11 --- ---
128 Standard hue Setting/Acqui-
sition
0 to 359 0 --- ---
129 Hue range Setting/Acqui-
sition
10 to 180 90 --- ---
130 Chroma upper limit Setting/Acqui-
sition
0 to 255 255 --- ---
131 Chroma lower limit Setting/Acqui-
sition
0 to 255 0 --- ---
