External Reference Parameters
FQ2-S4 User’s Manual
539
Appendices
12
Edge Width
310 Logging
condi-
tions
Data logging switch for
entire unit
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
311 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
312 Data logging switch for
detected edge position
X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
313 Data logging switch for
detected edge position
Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
314
Data logging switch
for standard position X
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
315
Data logging switch
for standard position Y
Setting/Acqui-
sition
0: Data logging OFF,
1: Data logging ON
1 --- ---
700 Display
settings
Edge position offset
display
Setting/Acqui-
sition
0: Display, 1: Do not display 1 --- ---
701 Detected edge position
X display
Setting/Acqui-
sition
0: Display, 1: Do not display 1 --- ---
702 Detected edge position
Y display
Setting/Acqui-
sition
0: Display, 1: Do not display 1 --- ---
800 Detected edge position
X display pattern
Setting/Acqui-
sition
0: Display, 1: Do not display 1 --- ---
801 Detected edge position
Y display pattern
Setting/Acqui-
sition
0: Display, 1: Do not display 1 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not mea-
sured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed
error,
−14: Figure not registered error,
−15: Out of range error
−2JG ---
7 Difference in edge
width
Acquisition
only
0 to 99,999.9999 0 DF Logged data
121 Set color Set color Setting/Acqui-
sition
Edge color specification
0: Not specified,
1: Specified
0 --- ---
131 Mea-
sure-
ment
condi-
tions
Edge color red Setting/Acqui-
sition
0 to 255 255 --- ---
132 Edge color green Setting/Acqui-
sition
0 to 255 255 --- ---
133 Edge color blue Setting/Acqui-
sition
0 to 255 255 --- ---
137 Edge level Setting/Acqui-
sition
0 to 100 50 --- ---
139 Noise level Setting/Acqui-
sition
5 to 442 5 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
