Omron FQ2-S4 User Manual

External Reference Parameters
512
FQ2-S4 User’s Manual
Bar code
700 Display
settings
Position compensation
theta display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
701 Detected edge angle
display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
702 Detected edge position
X0 display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
703 Detected edge position
Y0 display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
704 Detected edge position
X1 display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
705 Detected edge position
Y1 display
Setting/Acqui-
sition
0: ON, 1: OFF 0 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
0Mea-
sure-
ment
result
Judgement Acquisition
only
−2: No judgement (not mea-
sured),
0: Judgement is OK,
1: Judgement is NG,
13: Teaching not performed
error,
14: Figure not registered
error,
15: Out of range error,
−16: Measurement timeout
error
−2 JG Logged data
5 Index No. Acquisition
only
−2: Verification OFF,
or reading error
−1: Verification is NG,
0 to 31: Master data No.
−2 IN ---
6 Num. of characters Acquisition
only
0 to 1024 0 N Logged data
7
*1
Characters Acquisition
only
32 characters max. 0 --- ---
103 Output
parame-
ter
Reflect Setting/Acqui-
sition
0: Yes, 1: No 0 --- ---
121 Verifica-
tion con-
dition
Verified master data Settings/
Acquisition
−1: OFF
0: Verify all master data
1: Verify master data 0
2: Verify master data 1
31: Verify master data 31
0 --- ---
122 Partial verif. on/off Settings/
Acquisition
0: None
1: Enable
0 --- ---
123 Last compared digit Settings/
Acquisition
1 to 1024 1024 --- ---
124 First compared digit Settings/
Acquisition
1 to 1024 1 --- ---
External
refer-
ence
number
Category Data name Setting/Acqui-
sition
Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
...
