External Reference Parameters
FQ2-S4 User’s Manual
519
Appendices
12
*1 To acquire the detected text string, use the ITEMDATA2 command.
OCR
410 Logging
condi-
tions
Data logging switch for
unit
Setting/Acqui-
sition
0: Data logging OFF
1: Data logging ON
1 ---
---
411 Data logging switch for
judgement
Setting/Acqui-
sition
0: Data logging OFF
1: Data logging ON
1 --- ---
412 Data logging switch for
number of characters
Setting/Acqui-
sition
0: Data logging OFF
1: Data logging ON
1 --- ---
413 Data logging switch for
cell recognition rate
Setting/Acqui-
sition
0: Data logging OFF
1: Data logging ON
1 --- ---
414 Data logging switch for
contrast
Setting/Acqui-
sition
0: Data logging OFF
1: Data logging ON
1 --- ---
415 Data logging switch for
focus
Setting/Acqui-
sition
0: Data logging OFF
1: Data logging ON
1 --- ---
501 Display
setting
Character display Setting/Acqui-
sition
0: OFF 1: ON 1 --- ---
502 Cell recognition rate
display
Setting/Acqui-
sition
0: OFF 1: ON 1 --- ---
503 Contrast display Setting/Acqui-
sition
0: OFF 1: ON 1 --- ---
504 Focus display Setting/Acqui-
sition
0: OFF 1: ON 1 --- ---
External
refer-
ence
number
Category Data name Setting/Acquisition Data range Default Expres-
sion text
string
Logged
data/
Judge-
ment
parame-
ter
0 Measurement
result
Judgement Acquisition only −2: No judgement (not measured),
0: Judgement is OK,
−1: Judgement is NG,
−13: Teaching not performed error,
−14: Figure not registered error,
−15: Out of range error,
−16: Measurement timeout error,
−17: Format not entered error
−2 JG Logged
data
5 Index number Acquisition only −2: Verification result is OFF or read
was NG,
−1: Verification result is NG
0 to 31: Master data number
−2 IN Logged
data
6 Number of charac-
ters
Acquisition only 0 to 128 0 N Logged
data
7 Read character
string
Acquisition only 128 characters max. 0 -- ---
8 Similarity Acquisition only 0 to 100 0 SIM Logged
data
9 Stability Acquisition only 0 to 100 0 STB Logged
data
103 Output parame-
ter
Reflect Setting/Acquisition 0: Yes, 1: No 0 --- ---
External
refer-
ence
number
Category Data name Set/acquired Data range Default Text string
assigned
to
Ethernet
output
setting
Logged
