FQ2-S4 User’s Manual
Run Tab Page (from Setup Display)
Tool
Setup Mode
Continuous test
Model region Same as for the Search item settings. Scene
Insp. region Scene
Adjust judgement Adjusts judgement parameters without
stopping measurements.
--- Scene p. 219
Auto adjustment Automatically adjusts the judgement
parameters by using actual workpieces
which are considered as good or faulty
products.
OK Teach, NG Teach
Display setting Specifies whether to display individual
inspection results.
Depends on the measurement data item
for the inspection item.
Method Selects the expression to use to auto-
matically adjust the judgement parame-
ters.
Threshold (minimum), Threshold (aver-
age) (default), or Threshold (maximum)
Auto display (trend
monitor and histo-
gram only)
Same as the trend monitor and histogram for [Run] Mode. --- p. 228,
p. 229
Display range (trend
monitor and histo-
gram only)
Number of data
(trend monitor only)
p. 228
Number of data
(histogram only)
p. 229
Erase display
Save data Saves scene data, Calibration data, and
system data.
--- --- p. 222
Menu command Description Setting range Data Refer-
ence
Switch to Run mode Switches to Run Mode. --- --- p. 224
Menu command Description Setting range Data Refer-
ence
Select scene --- --- p. 234
Select Switches to a registered scene. ---
Rename Used to delete, copy, or change the
name of a scene.
15 alphanumeric characters
Copy ---
Clear
Menu command Description Setting range Data Refer-
ence
To Next Page
