R01UH0823EJ0100 Rev.1.00 Page 550 of 1823

Jul 31, 2019

RX23W Group 23. Multi-Function Timer Pulse Unit 2 (MTU2a)

Figure 23.37 Block Diagram of MTU3 and MTU4 in Complementary PWM Mode

MTU3.TGRC

TDDR

MTU3.TCNT

MTU3.TGRD MTU4.TGRDMTU4.TGRC

TCNTS

MTU4.TCNT

MTU3. TGRA

TCDR

TCBR

Comparator

Match

signal

Match

signal

PWM cycle

output

PWM output 1

PWM output 2

PWM output 3

PWM output 4

PWM output 5

PWM output 6

POE0#

POE1#

External cutoff

input

External cutoff

interrupt

: Registers that can always be read or written from the CPU

: Registers that can be read or written from the CPU

(but for which access disabling can be set by TRWER)

: Registers that cannot be read or written from the CPU

(except for TCNTS, which can only be read)

Output protection circuit

Output controller

TEMP 1

MTU3. TGRB

TEMP 2

TEMP 3

MTU4. TGRA

MTU4. TGRB

MTU4.TCNT underflow

interrupt

MTU3.TGRA compare-

match interrupt

POE3#
