Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
143
5.2
Synchronizing drive data files between NC and drive (PPU161.3 and
PPU160.2 only)
Note
This function is available on the PPU16
1.3 and PPU160.2 only.
The NC always compares its data backup with the drive data upon every startup.
● If no data backup files can be found, the NC creates a new backup file automatically with the following message
displaying on the screen:
● If the drive data differs from the NC data backup, data synchronization is required for synchronizing the drive data files
between the NC and the drives.
Operating sequence
1.
Press this softkey to enter the setting window when the following data synchronization di
a-
log box appears.
Note:
a password input field appears in this dialog if you have not set an access level on the
control system. For more information, see Secti
on "Setting the password (Page 144)".
If you cancel the data synchronization with the following softkey, this dialog appears again
on next NC start
up.
2.
Select a drive for which you desire to perform the data synchronization.
3.
Press this key to choose a synchronization method for the selected driv
e.
4.
Press this softkey to confirm your settings and start the data synchronization.
