Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
409
Parameter
MOTION-CONNECT 500 power
cable
MOTION-CONNECT 300 encoder
cable
Operation temperature
-20 °C to 80 °C
-30 °C to 60 °C
Shielding
Yes (coverage ≥ 80%)
Yes
Minimum bending radius, static
5 × outer diameter
Minimum bending radius, dynamic 180 mm, 210 mm, 360 mm,
440 mm
20 × outer diameter
Bending cycles
100000
Oil resistance
DIN VDE 472-803 Part B
EN60811-2-1 fulfilled
Flame-retardant
IEC 332.1
EN60332-1-1 to 1-3 fulfilled
Certification
RoHS and CE
RoHS
15.4.3
Cables for the SINAMICS V60 servo system
Parameter
MOTION-CONNECT power
cable
MOTION-CONNECT en-
coder cable
MOTION-CONNECT
brake cable
Jacket material
PVC
Degree of protection (motor-side
only)
IP54
Number of cores
4
14
2
Cross-section of cores
4 × 2.5 mm
2
14 × 24 AWG
2 × 0.75 mm
2
Operation voltage
600 V/1000 V
30 V
30 V
Operation temperature
-25 °C to 80 °C
Shielding
No
Yes
No
Minimum bending radius, static
50 mm
40 mm
25 mm
Minimum bending radius, dynamic
200 mm
160 mm
100 mm
Bending cycles 100000
Oil resistance
EN60811-2-1 fulfilled
Flame-retardant EN60332-1-1 to 1-3 fulfilled
Certification
RoHS and CE
RoHS
RoHS
