Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
433
3 Axis trav-
ersing key
(↑x)
Spindle
override
key (-)
CYCLE
START
CYCLE
STOP
RESET SPINDLE
RIGHT
SPINDLE
STOP
SPINDLE
LEFT
4 M01 PROGRAM
TEST
Axis trav-
ersing key
(↓x)
Spindle
override
key (+)
Axis trav-
ersing key
(→z)
RAPID Axis trav-
ersing key
(←z)
Spindle
override
key (100%)
8 1
1)
1
1)
7 SEG LED1
2)
9
1
1)
1
1)
7 SEG LED2
2)
1)
To ensure the correct display of the active tool number, make sure that you set Bit 4 and Bit 5 to 1.
2)
You can set only values 0 to 9 for each 7-segment LED (LED1 and LED2).
17.2
Reading/Writing NC data
17.2.1
Reading/writing NC data: Job
DB1200
Reading/writing NC data [r/w]
PLC → NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Write varia-
ble
Start
1
Number of variables
2
3
DB1200 ...
1203
Reading/writing NC data [r/w]
PLC → NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000
Variable index
1001
Area number
1002
Line index for the NCK variable x (WORD)
1004
Column index for the NCK variable x (WORD)
1006
1008
Writing: data to NCK variable x (data type of the variables: 1 to 4 bytes)
17.2.2
Reading/writing NC data: Result
DB1200
Reading/writing NC data [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
2000 Error in job Job com-
pleted
2001
2002
DB1200 ...
1203
Reading/writing NC data [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
3000 Error has
occurred
Valid varia-
ble
3001
Access result
1)
3002
