Bit
Description of the parameters
Entry
6
Default value
Value is missing in the cycle if no entry is made.
7
Separator
/
8 Short parameter text $ + the identifier (the short description of the selected
parameter, which will display in the upper left corner of the
parameter screen; defined in the extended user text file)
9
End of variable definition
)
10
Start of description
[
11 Parameter name Text preceding the input field; a maximum of five charac-
ters in length
12
End of description
]
13 Parameter-specific image /B + bmp file name (without file extension)
Note
Separators, start and end identifiers must always be entered.
The bits 4, 6, and 13 ca
n be left blank.
If no texts are stored with the $ identifier, three question marks appear in the associated fields on the screen.
Example
//CN1(CYCLE100)
(R/0 99999.999//$83020)[DIA]
(R/0 99999.999//$83021)[DIAF]
(R/-9999.999 99999.999//$83022)[STAP]
(R/-9999.999 99999.999//$83023)[ENDP]
(R/0 99999.999//$83024)[MID]
(R/0 99999.999//$83025)[UX]
(I/*0 1 2/0/$83026)[MACH]/B CN1
(R/1 99999.999/1/$83027)[VRT]
M17
13.4.7
Transferring the desired files to the control system
Proceed as follows to transfer the required files to the control system.
Prerequisite:
A USB memory stick which contains all required files is inserted into the USB interface at the front of the PPU.
Transferring the user cycle file
+
1.
Select the system data operating area.
2.
Open the USB storage directory through the following softkey operations:
→
3.
Select the desired user cycle file (for example, CYCLE100.SPF) and then press this softkey
to cop
y the file.
4.
Press this softkey to open the user
cycle directory.
5.
Press this softkey to paste the
file.
