13.7
PI service functions
The following PI service functions are supported on the control system:
● ASUP function
● Deleting a password
PLC interface address
DB1200
PI service [r/w]
PLC → NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
4000
Start
4001
PI index
DB1200
Reading/writing NC data [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
5000 Error in job Job com-
pleted
DB3400
ASUP: Result [r/w]
PLC → NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 INT1
Start
1 INT2
Start
DB3400
ASUP: Result [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000
INT1
ASUP exe-
cution not
possible
Interrupt
no. not
allocated
ASUP is
being exe-
cuted
ASUP end-
ed
1001
INT2
ASUP exe-
cution not
possible
Interrupt
no. not
allocated
ASUP is
being exe-
cuted
ASUP end-
ed
ASUP function
The ASUP function means the execution of the program PLCASUP1.SPF or PLCASUP2.SPF called by the PLC. The two
ASUPs cannot be simultaneously executed, and PLCASUP1.SPF has a higher priority over PLCASUP2.SPF.
In a PLC program, firstly you must initialize the ASUP by setting "PI index" (DB1200.DBB4001) and "NCK read/write start"
(DB1200.DBX4000.0), and then use a rising edge to trigger "ASUP1 start" (DB3400.DBX0.0) or "ASUP2 start"
(DB3400.DBX1.0).
The control system provides two default ASUPs for the PLC. ASUP1 is used for manual tool change and ASUP2 is used for
the manual machine of the workpiece on a turning machine with the Manual Machine Plus function.
You can also use your own ASUPs as required. To do so, you must first place your programs (PLCASUP1.SPF and
PLCASUP2.SPF) in the manufacturer cycle directory (N:\CMA), and then set "PI index" (DB1200.DBB4001) to 1 (ASUP1)/2
(ASUP2).
