Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
442 01/2017
3036
Extended address M function 5 (byte)
17.7.5
Transferred S functions
DB2500
S functions from NCK channel [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
4000
S function 1 (REAL) (DINT)
4004
Extended address S function 1 (byte)
4008
S function 2 (REAL)
4012
Extended address S function 2 (byte)
4016
4020
17.7.6
Transferred D functions
DB2500
D functions from NCK channel [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
5000
D function 1 (DINT)
5004
17.7.7
Transferred H functions
DB2500
H functions from NCK channel [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
6000
H function 1 (REAL) (DINT)
6004
Extended address H function 1 (byte)
6008
H function 2 (REAL)
6012
Extended address H function 2 (byte)
6016
H function 3 (REAL)
6020
Extended address H function 3 (byte)
17.8
NCK signals
17.8.1
General signals to NCK
DB2600
General signals to NCK [r/w]
PLC → NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Protection level
Keyswitch position 0 to 3
Acknowled
ge
EMERGEN
CY STOP
EMERGEN
CY STOP
Braking
along the
contour in
case of
EMERGEN
CY STOP
4 5 6 7
1 Request
axis dis-
tances to
go
Request
axis actual
values
INC inputs
in mode
signal
range ac-
tive
1)
2
