Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
54 01/2017
10.
Click the
button in the toolbar or select from the main window menu as follows to call
the connection dialog box:
11.
Select the network connections option and click this button to create new conne
ction.
12.
Assign the parameters for a new network connection in the dialog box. Note that the a
c
cess
level and password must be specified according to those set on
the HMI.
Note:
To avoid unauthorized access of the controller, change the Siemens default pass-
words to your own ones. For more information about changing a password, see Section
"
Setting the password (Page 144)".
13.
After you finish the editing, click this button to save the settings.
14.
Click the following button or simply double
-click the connection option to establish the con-
nection.
2.3
Personal computer
A personal computer with the following basic configuration is necessary for commissioning:
● Operating system: Windows Vista (both 32-bit and 64-bit versions)/Windows 7 (both 32-bit and 64-bit versions)
● Hard drive capacity: > 40 GB
● Memory capacity: > 1 GB
● Ethernet interface: for NC, PLC, and drive commissioning
● RJ45 Ethernet cable
