439
3002
Alarm 24
Alarm 23
Alarm 22
Alarm 21
Alarm 20
Alarm 19
Alarm 18
Alarm 17
3003
Alarm 32
Alarm 31
Alarm 30
Alarm 29
Alarm 28
Alarm 27
Alarm 26
Alarm 25
17.6.8
Signals from operator panel (retentive area)
DB1900
Signals from operator panel [r/w]
HMI -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Switch over
Ma-
chine/Work
Simulation
active
1
2
3
4
6
7
17.6.9
General selection/status signals from HMI (retentive area)
DB1900
Signals from HMI [r]
HMI -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000
1001
1002
1003
Axis number for handwheel 1
Machine
axis
Handwheel
selected
Contour
handwheel
C B A
1004
Axis number for handwheel 2
Machine
axis
Handwheel
selected
Contour
handwheel
C B A
1005
1006
1007
17.6.10
General selection/status signals to HMI (retentive area)
DB1900
Signals to HMI [r/w]
PLC -> HMI interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
5000 OP key
block
5001
5002 Enable
measure-
ment in
JOG
5003
